shanghai donsun cutting machine LGK-70BS/80B/100B/120B/160B
Industrial grade cutting
Adopt Advanced IGBT Module technology of the core Inverter device.
Untouch Start System-Smooth Arc-Striking with HF Control. 330V~500V wide voltage range
Rapid ArC Restrike- Quality narrow cutting and excellent travel speed. Function Post Gas for effective cooling of the cutting torch. Competltive Cutting Thickness(Carbon Steel)-
Recommended thickness:40mm. Cool Operation, Long Consumable Life-Cutting accessories
with competitive price and performance Engine Drive Compatible-Wide range for input
voltage, Select a suitable Engine Drive in гemote locations. Auto-Protectlon agalnst Low alr pressure, over-voltage, over-current and over-heatedEnergy Saving – Compared with the traditional cutting machine more efficient.
Inverter technology
Intelligent air cooling
Lack voltage/over current /over heat protection
Outside compressor
Intelligent interface adjustment
| Model | CUT-70BS | CUT-808 | CUT-100B | CUT-120B | CUT-160B |
| Input voltage(V) | 220/380v | 3P 380V | 3P 380V | 3P 380V | 3P 380V |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated input current(A) | 46/15.4 | 22 | 30.5 | 38.3 | 47 |
| Duty cycle(%)(40℃) | 60 | 60 | 60 | 60 | 60 |
| No-load voltage(V) | 337.5 | 337.5 | 337.5 | 331 | 342 |
| Output current (A) | 25-65 | 25-85 | 25-110 | 25-130 | 25-160 |
| Output voltage(V) | 106 | 114 | 124 | 132 | 140 |
| ARC-initiating | H-F Untouch | H-F Untouch | H-F Untouch | H-F Untouch | H-F Untouch |
| Efficiency(%) | 95 | 95 | 95 | 95 | 95 |
| Cutting thickness (mm) | 20 | 30 | 45 | 55 | 60 |
| Weight (kg) | 14 | 26 | 30 | 32 | 35 |
| Dimension(mm) | 440*220*400 | 570*290*550 | 570*290*550 | 70*290*550 | 570*290*550
|
