shanghai donsun LGK-80/100DV/100N/100BN/120BN/160BN plasma cutting welding machine
INDUSTRIAL BUILT-IN COMPRESSOR.CUT.MMA
- Adopt Advanced IGBT Module technology of the core Inverter device.Untouch Start System-Smooth Arc-Striking with HF Control.330V~500V wide voltage range Rapid ArC Restrike- Quality narrow cutting and excellent travel speed. Function Post Gas for effective cooling of the cutting torch. Competltive Cutting Thickness(Carbon Steel)- Recommended thickness:40mm. Cool Operation, Long Consumable Life-Cutting accessories with competitive price and performance Engine Drive Compatible-Wide range for input voltage, Select a suitable Engine Drive in гemote locations. Auto-Protectlon agalnst Low alr pressure, over-voltage, over- current and over-heated Energy Saving – Compared with the traditional cutting machine more efficient
Inverter technology
Intelligent air cooling
Built-in/Outside compressor
ARC-PLASMA CUTTING dual functions
Intelligent interface adjustment
Model | CUT-800V | CUT-100DV | CUT-100N | CUT-100BN | CUT-120BN | CUT-160BN |
Input voltage(V) | 220/380v | 220/380v | 3P 380V | 3P 380V | 3P 380V | 3P 380V |
Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
Rated input current(A) | 52/21.4 | 52/28 | 28 | 33 | 36.5 | 44 |
Duty cycle(%)(40℃) | 60 | 60 | 60 | 60 | 60 | 60 |
No-load voltage(V) | 337.5 | 337.5 | 337.5 | 337.5 | 337.5 | 335 |
Output current (A) | 25-65 | 25-65/85 | 25-85 | 25-100 | 25-110 | 25-135 |
Output voltage(V) | 106 | 114 | 114 | 120 | 124 | 134 |
ARC current(A) | 260 | 260 | 260 | 260 | 260 | 280 |
ARC voltage(V) | 68 | 68 | 68 | 68 | 68 | 75 |
ARC-initiating | H-F Untouch | H-F Untouch | H-F Untouch | H-F Untouch | H-F Untouch | H-F Untouch |
Efficiency(%) | 85 | 85 | 85 | 85 | 85 | 85 |
Cutting thickness (mm) | 25 | 35 | 35 | 40 | 45 | 55 |
Weight (kg) | 29 | 35.5 | 35 | 37 | 37 | 55 |
Dimension(mm) | 520*250*510 | 570*280*550 | 570*280*550 | 570*300*550 | 570*300*550 | 670*330*610
|
